WEGC Range Radio Communications Protocol
West End Gun Club is piloting radio communications at the range to further coordinate communications between RSO’s, Match Directors and Members with GMRS radios.
Range wide cease fire
Emergency medical assistance
Fire coordination and suppression
Vehicle assistance
Range event coordination
Bay and member coordination
General Mobile Radio Service (GMRS) is a popular public radio communication system in areas where cell phone reception is non existent. Many WEGC members use GRMS already, thus the intent of this protocol is to establish a working protocol and encourage the use of GRMS as an additional resource for communication between members and staff (including matches) while on WEGC property. Members would not be required, but are encouraged to use GMRS. Low power GMRS radio checks have been done throughout the range property and the radio signal covers all areas of WEGC, all the way to the entrance of the canyon at the creek crossing.
In the event of an emergency during the weekday (Mon-Thurs) radio communications may not be monitored by range staff or other members. When arriving it’s good to do a radio check-in.
LICENSING
GMRS is a FCC licensed frequency and it is assumed that each member has their own license. Note that having a license is not required to communicate at the range however it’s highly encouraged to obtain one. GMRS licenses cost $35, are good for 10 years and apply to your entire immediate family; there is no test. The steps to get a license can be found here: https://radiothoughts.com/how-to-get-gmrs-license/
In case of an emergency anybody can use a GMRS or Ham radio to get help.
RECOMMENDED RADIOS
| Radio | See on Amazon | Features |
|---|---|---|
| TD-H3 |  | Bluetooth enabled and wireless programming |
| Baofeng UV-5R | | 5W Programmable with CHIRP, widely used |
| Baofeng AR-5RM | | 5W Programmable with CHIRP, widely used |
Table1 : Recommended Radios. Note that popular off the shelf brands like Midland and Cobra GMRS radios will also work.
RADIO CHANNEL USE
Here is a table of the channels we will be using. Note that these channels are subject to cross talk from nearby OHV users. Please keep range communications concise and to a minimum.
| CHANNEL | Frequency MHz | MAX Power | PRIMARY USE |
|---|---|---|---|
| 1 | 462.5625 | 5W | Default range wide frequency for RSO’s, Members and Directors |
| 2 | 462.5875 | 5W | Maintenance |
| 3 | 462.6125 | 5W | Event coordination |
| 4 | 462.6375 | 5W | Match coordination |
| 5 | 462.6625 | 5W | Match coordination |
| 6 | 462.6875 | 5W | Match coordination |
Table2 : WEGC Range Channels, Frequencies, and Protocols. Note that if more channels are needed, a match director can go up to channel 22 at their descretion.
